Processor | Intel® Xeon® E5 v3 |
---|---|
Processorfabrikant | Intel |
Processormodel | E5-2603V3 |
Processorsnelheid | 1,6 GHz |
Aantal processorkernen | 6 |
Processor cache | 15 MB |
Chipset moederbord | Intel C610 |
Geheugenkanalen ondersteund door processor | Quad |
Aantal geïnstalleerde processoren | 1 |
Thermal Design Power (TDP) | 85 W |
Processor cache type | Smart Cache |
Systeembus | 6,4 GT/s |
Max. aantal SMP-processoren | 2 |
Processor socket | LGA 2011-v3 |
Processor lithografie | 22 nm |
Processor aantal threads | 6 |
Processor operating modes | 64-bit |
Stepping | R2 |
FSB Parity | |
Bus type | QPI |
aantal QPI links | 2 |
Codenaam processor | Haswell |
Tcase | 72,8 °C |
Maximaal intern geheugen ondersteund door processor | 768 GB |
Geheugentypen ondersteund door processor | DDR4-SDRAM |
Klokgeheugen-snelheden ondersteund door processor | 1600 MHz |
Geheugenbandbreedte ondersteund door de processor ( max) | 51 GB/s |
ECC ondersteund door processor | |
Execute Disable Bit | |
Idle States | |
Thermal Monitoring Technologies | |
Maximaal aantal PCI Express-lijnen | 40 |
PCI Express configuraties | x4, x8, x16 |
Verpakkingsgrootte processor | 52.5 x 45 mm |
Ondersteunde instructie sets | AVX 2.0 |
Schaalbaarheid | 2S |
Physical Address Extension (PAE) | 46 Bit |
Ingebouwde opties beschikbaar | |
Processorserie | Intel Xeon E5-2600 v3 |
Conflictvrije processor |
Intern geheugen | 8 GB |
---|---|
Intern geheugentype | DDR4-SDRAM |
Maximum intern geheugen | 384 GB |
Geheugenslots | 24x DIMM |
ECC | |
Kloksnelheid geheugen | 2133 MHz |
Geheugenlayout | 1 x 8 GB |
Maximale opslagcapaciteit | 38,4 TB |
---|---|
RAID support | |
Soort optische drive | |
HDD interface | SATA |
HDD omvang | 2.5" |
Maximum aantal HDD's per behuizing | 8 |
Soorten RAID | 0, 1, 5, 10 |
Hot-plug ondersteuning |
LAN controller | Broadcom 5720 |
---|---|
Ethernet LAN | |
Bekabelingstechnologie | 10/100/1000Base-T(X) |
Ethernet interface type | Gigabit Ethernet |
Aantal Ethernet LAN (RJ-45)-poorten | 4 |
---|---|
Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A | 3 |
VGA (D-Sub)poort(en) | 1 |
Seriële poort(en) | 1 |
PCI Express slots versie | 3.0 |
---|
Type behuizing | Rack (1U) |
---|---|
Rack-montage |
OS | |
---|---|
Compatibele besturingssystemen | Microsoft Windows Server Red Hat Enterprise Linux (RHEL) SUSE Linux Enterprise Server (SLES) Canonical Ubuntu Oracle Linux CentOS VMware Citrix XenServer Oracle Solaris Wind River Linux |
CPU configuratie (max) | 2 |
---|---|
Intel® Rapid Storage Technology | |
Enhanced Intel SpeedStep Technology | |
Intel® Identity Protection Technology (Intel® IPT) | |
Intel® Wireless Display (Intel® WiDi) | |
Intel® Virtualization Technology for Directed I/O (VT-d) | |
Intel® Anti-Theft Technology (Intel® AT) | |
Intel® Hyper Threading Technology (Intel® HT Technology) | |
Intel® My WiFi Technology (Intel® MWT) | |
Intel® Turbo Boost Technology | |
Intel® Quick Sync Video Technology | |
Intel® InTru™ 3D Technology | |
Intel® Clear Video HD Technology (Intel® CVT HD) | |
Intel® Insider™ | |
Intel® Flex Memory Access | |
Intel® AES New Instructions (Intel® AES-NI) | |
Intel® Trusted Execution Technology | |
Intel® Enhanced Halt State | |
Intel® VT-x with Extended Page Tables (EPT) | |
Intel® Demand Based Switching | |
Intel® Secure Key | |
Intel® TSX-NI | |
Intel® OS Guard | |
Intel® Clear Video-technologie | |
Intel® Clear Video Technology for Mobile Internet Devices (Intel® CVT for MID) | |
Intel® 64 | |
Versie Intel® Identity Protection Technology | 0, 00 |
Versie Intel® Secure Key Technology | 1, 00 |
Intel® Virtualization Technology (VT-x) | |
Versie Intel® TSX-NI | 0, 00 |
Intel® Dual Display Capable Technology | |
Intel® FDI Technology | |
Intel® Fast Memory Access | |
ARK ID processor | 83349 |
Netvoeding | 500 W |
---|---|
Aantal hoofdvoedingen | 1 |
Breedte | 434,7 mm |
---|---|
Diepte | 698,5 mm |
Hoogte | 43,2 mm |
Gewicht | 12,2 kg |
Duurzaamheidscertificaten | ENERGY STAR |
---|
